Frequency Response (-6dB anechoic chamber test) : 46Hz-22kHz.

Nominal Impedance : 8Ω.

Rated power AES : 55W.

Tweeter : 1*1“, 1” voice coil

Woofer: 1*5.0“, 1.5” voice coil.

Directivity(-6dB angle H°*V°) : 105°*105°

Maximum sound pressure level (1m) continuous/peak : 108dB/114dB.

Processor: Built-in electronic crossover, high precision 96kHz signal sampling frequency, 24-bit quantization precision.

Preset Program : Standard (Standard Acoustic Audio)

Amplifier Line Type : Class D.

Amplifier Power Rating AES : 120W.

Amplifier Frequency Response (1W8Ω mono) : 10Hz-30kHz (±0.5dB).

Intermodulation distortion : <0.05%.

Total harmonic distortion : <0.05%.

Input method: XLR male/female/RCA.

Cooling method: Physical self-dissipating heat dissipation.

Operating temperature: -20℃-80℃.

Power supply range: AC190V--240V 50/60 Hz.

System protection settings: DC protection / short circuit protection / overheating protection / overload protection / soft start protection / overvoltage protection / undervoltage protection.

Enclosure Material: High quality plywood, CNC precision crafted.

Power socket: 1pc.

Net weight : 3.3kg.

Dimension (W*H*D) : 188*272*220mm.
