Receiver technical parameters

Working frequency: 500-980MHz

Channel: 4*50 channels can be adjusted frequency

Infrared to frequency, frequency of the same frequency technology

The display shows the transmitter battery power

S/N signal-to-noise ratio: >105dB

T.H.D distortion: <0.5%

Frequency Response:40Hz-18KHz

Noise lock squelch control + audio navigation lock squelch

Long-distance line design, the use of distance up to 60-150 meters

Transmitter technical parameters

Channel: 200 channels

Bandwidth: 50MHz

Channel interval: 300KHz

Frequency Stability: ±0.005%

Battery: 2 AA batteries / 5 batteries
