Receiver technical parameters

Working frequency: 500-980MHz

Infrared frequency pairing, frequency co-frequency technology

Display shows the transmitter battery power

S/N signal-to-noise ratio: >105dB

T.H.D Distortion:<0.5%

Frequency Response:40Hz-18KHz

Noise lock squelch control + audio navigation lock squelch

True diversity long-distance line design, outdoor use distance up to 300 meters

Transmitter technical parameters

Channel: 200 channels

Bandwidth: 50MHz

Channel interval: 250KHz

Frequency Stability: ±0.005%

Battery: 2 AA batteries/5 batteries

Transmit power can be set:

High power 15mV = 300 meters (battery can last 2 hours)

Power 10mV = 150-200 meters (battery can last 4-5 hours)
