Analog Inputs 2CH-XLR and 1/4" TRS (female) inputs, electronically balanced/unbalanced

Input Impedance Balanced 47Ω, Unbalanced 20KΩ

Maximum Line Level Input +18dBµ

Analog Outputs 2CH-XLR and 1/4" TRS (female) outputs, electronically balanced/unbalanced

Output Impedance Balanced >120Ω, Unbalanced >60Ω

Maximum Output Level +20dBµ

Frequency Response 20Hz-20KHz, ±0.3dB

Signal-to-noise ratio >105dB(A)

Dynamic Range 103dB

Total Harmonic Distortion + Noise 0.005%,1KHz; 20Hz-10KHz, <0.01%; 10KHz-20KHz, <0.025

Operating voltage 110V/220V/AC 50Hz/60Hz

Gross weight 2.7kg

Package size 560×260×90mm
