TP-515 Active Horn-loaded Speaker 50W
Product Features
■ Full aluminum alloy construction with stainless steel bracket and weatherproof horn-loaded transducer;
■ Integrated high-efficiency tweeter delivers superior sound projection and wide dispersion;
■ Class D digital amplifier circuit ensures high efficiency, low distortion, and minimal power loss;
■ 1 unbalanced signal input channel with independent volume control;
■ Auto power-saving mode disengages main amplifier when no signal is detected;
■ Wide DC input compatibility (12-24V) supports solar battery applications;
■ Designed for indoor/outdoor public address systems (plazas, stations, airports) with wall-mount installation;
Specifications
■ Output Power: 50W RMS
■ Power Consumption: ≤75W
■ Standby Consumption: <3W
■ Frequency Response: 380Hz-6.5kHz (±3dB)
■ Sensitivity: 109±3dB (1W/1m)
■ Total Harmonic Distortion (THD): ≤1% @1kHz
■ Signal-to-Noise Ratio: >65dB (A-weighted)
■ Protection Circuitry: Overload and short-circuit protection
■ Operating Temperature: 5℃ to 40℃
■ Humidity Range: 20%-80% RH (non-condensing)
■ Power Input: DC 24V/3A
■ Weatherproof Rating: IP66
■ Net Weight: 2.58kg (5.69lbs)
■ Dimensions: Φ325×350mm (Φ12.8×13.78")
■ Construction: Aluminum enclosure + U-shaped bracket
■ Finish: Grey
