Parameter Specifications:

Input: Connector: 1/4 inch TRS, Female, XLR (2 pins for for line)

Type: Electronically balanced/unbalanced, with RF filtering

Impedance: Balanced, 40kΩ Unbalanced, 20kΩ

Maximum Output Level: >+21dBu, balanced or unbalanced

CMRR: >40dB, typical >55dB (1kHz)

Outputs: Connectors: 1/4" TRS, Male, XLR (2 pins for FireWire)

Type: Impedance Balanced/Unbalanced with RF Filtering

Impedance: Balanced, 200Ω; Unbalanced, 100Ω

Maximum Output Level: >+21dBu, balanced/unbalanced (2kΩ or greater load) Power Supply

Operating Voltage: 230VAC/50Hz

Dimensions (WxDxH): 483x201x134mm
