Provides 12 inputs

8 mono, 2 stereo

3-band EQ equalizer per channel

60MM fader

1AUX, 1 Group Return, 2 Groups, 1 Stereo Outputs

Built-in DSP digital effects

7-band graphic equalizerBuilt-in high-quality USB player with display

Bluetooth display

+48V phantom power

Total harmonic distortion: less than 0.1 percent

Frequency Response: 20Hz-20KHz.

+1dB-3dB

Input and output impedance:

Mic Input: 2.4KΩ

Line Input: 11KΩ

Stereo Input: 100KΩ

Main Output Impedance: 75Ω

Grouping Impedance: 75Ω

AUX Output Impedance: 75Ω

EQ (Mono Input)

High Frequency: 12KHz±15dB

Midrange: 2.5Hz±15dB

Low frequency: 80Hz±15dB

Operating conditions:

Temperature range: -10℃~+45℃

Power supply: AC 220V 50/60Hz

Power consumption: 30W

Dimensions (L x W x H): 477 mm x 313 mm x 638 mm

Net weight: 6.8 kg
