Product Features.

10" resistive touch screen 1280x800 resolution

17 x 100mm motorized faders

Chinese and English interfaces can be switched at any time without rebooting.

Built-in USB recording and playback function

Can play APE, FLAC, MP3, WAV lossless audio formats

USB player can recognize Chinese song titles

Built-in 16-channel independent feedback suppressor

Built-in 16-channel automatic mixing

With 8 DCA

iPad touch screen full-function control, real-time data synchronization

Optional WIFI hotspot

Support 8 terminals control at the same time

Built-in 2 effector modules

ARM firmware and DSP firmware can be upgraded via network or USB resistance disk.

Each input channel has 4-band parameter equalization, noise gate, feedback suppressor, high and low pass,

Compression, Inversion

Parametric EQ, Hi-Lo, Compression, Inverting, 1 second delay for each output channel.

Output channels L/R, 10BUS, HeadPhone (L/R)

10BUS mixing bus selectable pre-fader, post-fader (PRE/POST)

Support for 100 groups of scene preset function, can be exported, imported into the USB memory, easy to data backup

32 PEQ mode storage

Built-in signal generator: sine wave, pink noise, white noise

Channel parameter copy function, the same channel quickly copy data

Wiring: balanced input, output XLR

8 fader groups, 8 user-defined keys, 4 fast mute group buttons

With panel lock button (to prevent misuse)

Parameter Specifications.
