Dante Input Channels: 64

Dante Output Channels: 64

Audio Server

Processor:ADI SHARC 21489@450 MHz SIMD x 2;

DSP processing power:400 MIPS, 1.6 GFLOPS.

Sample Rate:48 kHz, ± 100 ppm.

8-band British parametric equalization, providing 5 filter options: Parametric,Lowshelf,Highshelf,Lowpass,Highpass;

Provide end-user customized operation interface, maximum support for 30 devices with the same interface management;

With central control function, support RS232, RS485, UDP three kinds of control mode, can be on the system of power supply, signal switching, environment control, audio and other overall control, to realize a key to open the system required functions.

Customized user interface is required;

Processor chip using ADI architecture, not less than 40bit DSP floating point computing engine

The number of Dante input and output channels is not less than 64*64;

Input and output quantization not less than 48KHz/24bit;

Input channels should have:

No less than 8-band PEQ, and provide no less than five filter types to choose from;

Output channels should have:

No less than 8-band PEQ, crossover, delay, limiter.

No less than a 64 x 64 matrix;

No less than 8 groups of presets;

No less than 8 GPIO and independently configurable inputs and outputs, which can be used as independent ADCs when configuring the inputs;

Supports input and output channel LINK and grouping functions;
