8Ω, dual-channel drive; 200W×2

4Ω, dual-channel drive: 300W×2

2Ω, dual-channel driver: 400W×2

8Ω, bridge drive: 600W

4Ω, bridge drive: 750W

Signal-to-noise ratio (20Hz-20kHz): 100dB

Input sensitivity: 0.775V/1.4V

Voltage gain (8Ω): 39.5dB

Output circuit: Class H

Distortion (1 dB below rated power, 20-20kHz): 8Ω, less than 0.05% 4Ω, less than 0.1%

Frequency Response: 20-20kHz, +0, -1dB

Damping factor: 500

Input impedance: 10K/20K Ohurs, unbalanced or balanced

Maximum input level: +24dB (16Vrms)

Input connector, each channel: 3-pin XLR male/female

Output connector, each channel: XLR, 1/4", binding post XLR, 1/4"

Amplifier and load protection: Short circuit, open circuit, thermal and RF protection Load protection for DC faults

Controls and Indicators, Front Panel: Gain Control, Red Clip LED, Proportional, 0.1% THD Threshold. Green signal LED, machine over temperature LED

Controls, Rear Panel: Stereo, Parallel, Bridge

Net weight: 12kg

Size (HWD): 88mm×483mm×320mm
