8Ω, dual-channel drive; 1000W×2

4Ω, dual-channel drive; 1500W×2

2Ω,Dual-channel driver: 2000W×2

8Ω, Bridge Driver: 3000W

4Ω, bridge drive: 3750W

Signal-to-noise ratio (20Hz-20kHz): 100dB

Input sensitivity: 0.775V/1.4V

Voltage gain (8Ω): 39.5dB

Output Circuit: Class H

Distortion (1 dB below rated power, 20-20kHz): 8Ω, less than 0.05% 4Ω, less than 0.1%

Frequency Response: 20-20kHz, +0, -1dB

Damping Factor: 500

Input Impedance: 10K/20K Ohurs, unbalanced or balanced

Maximum Input Level: +24dB(16Vrms)

Input connectors, each channel: 3-pin XLR male/female

Output connectors, each channel: Canon, 1/4", Terminal XLR, 1/4

Amplifier and load protection: short circuit, disconnect, thermal and RF protection Load protection against DC faults

Controls and Indications, front panel: gain control, red clipping LED, proportional, 0.1% THD threshold. Green signal LED, machine over temperature LED

Controls, rear panel: stereo, parallel, bridge

Net weight: 26.5kg

Size (HWD): 88mm x 483mm x 450mm
